GF-122 AERCO XPC GATEWAY
157
Modbus-To-N2 Protocol Mapping
4 ECS Heaters
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled Type
N2
ID
E Valve Addr 29
01-Cntl Output Signal boilerstate_1
30004/29  
data float 1
02-Setpoint effectsetpt_1
30006/29  
data float 2
03-RmSetpt rmsetpt_1
40027/29 
data float 3
04-Outlet Temp localsuptemp_1
30002/29  
data float 4
05-FBk Sensor Temp localrettemp_1
30290/29  
data float 5
06-Over Temp Alarm unitstat_1
30075/29  
data float 6
07-Flow Rate flowrate_1
30291/29  
data float 7
Use Metric Conversion m101_1

binary out 1
E Valve Addr 30
01-Cntl Output Signal boilerstate_2
30004/30  
data float 8
02-Setpoint effectsetpt_2
30006/30  
data float 9
03-RmSetpt rmsetpt_2
40027/30 
data float 10
04-Outlet Temp localsuptemp_2
30002/30  
data float 11
05-FBk Sensor Temp localrettemp_2
30290/30  
data float 12
06-Over Temp Alarm unitstat_2
30075/30  
data float 13
07-Flow Rate flowrate_2
30291/30  
data float 14
Use Metric Conversion m101_2

binary out 2
E Valve Addr 31
01-Cntl Output Signal boilerstate_3
30004/31  
data float 15
02-Setpoint effectsetpt_3
30006/31  
data float 16
03-RmSetpt rmsetpt_3
40027/31 
data float 17
04-Outlet Temp localsuptemp_3
30002/31  
data float 18
05-FBk Sensor Temp localrettemp_3
30290/31  
data float 19
06-Over Temp Alarm unitstat_3
30075/31  
data float 20
07-Flow Rate flowrate_3
30291/31  
data float 21
Use Metric Conversion m101_3

binary out 3
E Valve Addr 32
01-Cntl Output Signal boilerstate_4
30004/32  
data float 22
02-Setpoint effectsetpt_4
30006/32  
data float 23
03-RmSetpt rmsetpt_4
40027/32 
data float 24
04-Outlet Temp localsuptemp_4
30002/32  
data float 25
05-FBk Sensor Temp localrettemp_4
30290/32  
data float 26
06-Over Temp Alarm unitstat_4
30075/32  
data float 27
07-Flow Rate flowrate_4
30291/32  
data float 28
Use Metric Conversion m101_4

binary out 4
