GATEWAY COMMUNICATIONS MANUAL
180
Modbus-To-LonWorks Protocol Mapping 1 BMS II, 4 MLX Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
SNVT
# SNVT NAME SNVT
Element
# Direction Prio Auth Ack
Mlx Addr 1
01-Act Mod Lev boilerstate_1 41009/1
 
161 nvoMlxState1
incremental
count (9)
0
Output (non-
polled)
02-Target Setpoint effectsetpt_1 41019/1
 
162 nvoMlxSetpt1
incremental
count (9)
0
Output (non-
polled)
03-Req Outlet
Temp
setpt_1 41005/1 163 nviMlxSetptRq1
incremental
count (9)
0
Input (non-
polling)
04-Net Direct Drive boilercmd_1 40002/1 164 nviMlxCmd1
incremental
count (9)
0
Input (non-
polling)
05-Mod Lev In boilerload_1 41201/1
 
165 nvoMlxLoad1
incremental
count (9)
0
Output (non-
polled)
06-Flow Sens
Temp
localsuptemp_1 41003/1
 
166 nvoMlxSupTmp1
incremental
count (9)
0
Output (non-
polled)
07-Display Code dispcode_1 30001/1
 
168 nvoMlxDispCode1
incremental
count (9)
0
Output (non-
polled)
11-Error Code errcode_1 40001/1
 
169 nvoMlxErrCode1 51 0
Output (non-
polled)
08-Unit Status unitstat_1 30002/1
 
170 nvoMlxStat1
incremental
count (9)
0
Output (non-
polled)
09-Ret Flow Temp returntemp_1 41004/1
 
167 nvoMlxRetTmp1
incremental
count (9)
0
Output (non-
polled)
Mlx Addr 2
01-Act Mod Lev boilerstate_2 41009/2
 
171 nvoMlxState2
incremental
count (9)
0
Output (non-
polled)
02-Target Setpoint effectsetpt_2 41019/2
 
172 nvoMlxSetpt2
incremental
count (9)
0
Output (non-
polled)
03-Req Outlet
Temp
setpt_2 41005/2 173 nviMlxSetptRq2
incremental
count (9)
0
Input (non-
polling)
04-Net Direct Drive boilercmd_2 40002/2 174 nviMlxCmd2
incremental
count (9)
0
Input (non-
polling)
05-Mod Lev In boilerload_2 41201/2
 
175 nvoMlxLoad2
incremental
count (9)
0
Output (non-
polled)
06-Flow Sens
Temp
localsuptemp_2 41003/2
 
176 nvoMlxSupTmp2
incremental
count (9)
0
Output (non-
polled)
07-Display Code dispcode_2 30001/2
 
178 nvoMlxDispCode2
incremental
count (9)
0
Output (non-
polled)
11-Error Code errcode_2 40001/2
 
179 nvoMlxErrCode2 51 0
Output (non-
polled)
08-Unit Status unitstat_2 30002/2
 
180 nvoMlxStat2
incremental
count (9)
0
Output (non-
polled)
09-Ret Flow Temp returntemp_2 41004/2
 
177 nvoMlxRetTmp2
incremental
count (9)
0
Output (non-
polled)
Page 2 of 3
