Modbus-To-N2 Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled Type
N2
ID
BMS Addr 128
01-Fire Rate Out boilerstate_13 30005/128
 
data float 121
02-Header Set Temp effectsetpt_13 30006/128
 
data float 122
03-Net Header Set Temp setpt_13 40005/128

data float 123
04-Header Temp localsuptemp_13 30002/128
 
data float 124
05-Outside Air Temp localoatemp_13 30003/128
 
data float 125
06-Display Code dispcode_13 30011/128
 
data float 126
07-Num Boilers Fired blrfired_13 30008/128
 
data float 127
08-Num Boilers Online blronline_13 30009/128
 
data float 128
09-Last Blr Fired blrlast_13 30017/128
 
data float 129
10-Boiler 1 Status blr1stat_13 30018/128
 
data float 130
11-Boiler 2 Status blr2stat_13 30019/128
 
data float 131
12-Boiler 3 Status blr3stat_13 30020/128
 
data float 132
13-Boiler 4 Status blr4stat_13 30021/128
 
data float 133
14-Boiler 5 Status blr5stat_13 30022/128
 
data float 134
15-Boiler 6 Status blr6stat_13 30023/128
 
data float 135
16-Boiler 7 Status blr7stat_13 30024/128
 
data float 136
17-Boiler 8 Status blr8stat_13 30025/128
 
data float 137
18-Net Blr 1 Status blr9stat_13 30026/128
 
data float 138
19-Net Blr 2 Status blr10stat_13 30027/128
 
data float 139
20-Net Blr 3 Status blr11stat_13 30028/128
 
data float 140
21-Net Blr 4 Status blr12stat_13 30029/128
 
data float 141
22-Net Blr 5 Status blr13stat_13 30030/128
 
data float 142
23-Net Blr 6 Status blr14stat_13 30031/128
 
data float 143
24-Net Blr 7 Status blr15stat_13 30032/128
 
data float 144
25-Net Blr 8 Status blr16stat_13 30033/128
 
data float 145
26-Net Blr 9 Status blr17stat_13 30034/128
 
data float 146
27-Net Blr 10 Status blr18stat_13 30035/128
 
data float 147
28-Net Blr 11 Status blr19stat_13 30036/128
 
data float 148
29-Net Blr 12 Status blr20stat_13 30037/128
 
data float 149
Use Metric Conversion m101_13 binary out 25
