GATEWAY COMMUNICATIONS MANUAL
184
Modbus-To-LonWorks Protocol Mapping
4 ECS Heaters (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
SNVT
# SNVT NAME SNVT
Element
# Direction Prio Auth Ack
E Valve
Addr 31
01-Cntl Output
Signal
boilerstate_3
30004/31
 
221 nvoEcsState31
incremental
count (9)
0
Output (non-
polled)
02-Setpoint effectsetpt_3
30006/31
 
222 nvoEcsSetpt31
incremental
count (9)
0
Output (non-
polled)
03-RmSetpt rmsetpt_3
40027/31

223 nviEcsSetptRq31
incremental
count (9)
0
Input (non-
polling)
04-Outlet Temp localsuptemp_3
30002/31
 
224 nvoEcsSupTmp31
incremental
count (9)
0
Output (non-
polled)
05-FBk Sensor
Temp
localrettemp_3
30290/31
 
225 nvoEcsRetTmp31
incremental
count (9)
0
Output (non-
polled)
06-Over Temp
Alarm
unitstat_3
30075/31
 
226 nvoEcsStat31
incremental
count (9)
0
Output (non-
polled)
07-Flow Rate flowrate_3
30291/31
 
227 nvoEcsFlow31
incremental
count (9)
0
Output (non-
polled)
Use Metric
Conversion
m101_3

0
disabled NV
(0)
1
Output (non-
polled)
E Valve
Addr 32
01-Cntl Output
Signal
boilerstate_4
30004/32
 
231 nvoEcsState32
incremental
count (9)
0
Output (non-
polled)
02-Setpoint effectsetpt_4
30006/32
 
232 nvoEcsSetpt32
incremental
count (9)
0
Output (non-
polled)
03-RmSetpt rmsetpt_4
40027/32

233 nviEcsSetptRq32
incremental
count (9)
0
Input (non-
polling)
04-Outlet Temp localsuptemp_4
30002/32
 
234 nvoEcsSupTmp32
incremental
count (9)
0
Output (non-
polled)
05-FBk Sensor
Temp
localrettemp_4
30290/32
 
235 nvoEcsRetTmp32
incremental
count (9)
0
Output (non-
polled)
06-Over Temp
Alarm
unitstat_4
30075/32
 
236 nvoEcsStat32
incremental
count (9)
0
Output (non-
polled)
07-Flow Rate flowrate_4
30291/32
 
237 nvoEcsFlow32
incremental
count (9)
0
Output (non-
polled)
Use Metric
Conversion
m101_4

0
disabled NV
(0)
1
Output (non-
polled)
