Modbus-To-N2 Protocol Mapping
1 BMS II, 4 MLX Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled Type
N2
ID
Mlx Addr 3
01-Act Mod Lev boilerstate_3 41009/3
 
data float 164
02-Target Setpoint effectsetpt_3 41019/3
 
data float 165
03-Req Outlet Temp setpt_3 41005/3 data float 166
04-Net Direct Drive boilercmd_3 40002/3 data float 167
05-Mod Lev In boilerload_3 41201/3
 
data float 168
06-Flow Sens Temp localsuptemp_3 41003/3
 
data float 169
07-Display Code dispcode_3 30001/3
 
data float 170
11-Error Code errcode_3 40001/3
 
data float 171
08-Unit Status unitstat_3 30002/3
 
data float 172
09-Ret Flow Temp returntemp_3 41004/3
 
data float 173
Mlx Addr 4
01-Act Mod Lev boilerstate_4 41009/4
 
data float 175
02-Target Setpoint effectsetpt_4 41019/4
 
data float 176
03-Req Outlet Temp setpt_4 41005/4 data float 177
04-Net Direct Drive boilercmd_4 40002/4 data float 178
05-Mod Lev In boilerload_4 41201/4
 
data float 179
06-Flow Sens Temp localsuptemp_4 41003/4
 
data float 180
07-Display Code dispcode_4 30001/4
 
data float 181
11-Error Code errcode_4 40001/4
 
data float 182
08-Unit Status unitstat_4 30002/4
 
data float 183
09-Ret Flow Temp returntemp_4 41004/4
 
data float 184
