GATEWAY COMMUNICATIONS MANUAL
112
Date: 11/22/05
Vendor Name: OEM
Product Names: Extended
Protocol Converter
Product Model Number:
XPC
Applications Software Version: HW_Exec_B Firmware Revision: 2.03
Product Description:
The XPC is a general purpose building automation translator with custom programmable functionality,
designed for communicating through multiple protocols. Modbus registers are spawned within the device
as a result of downloading graphical control programs. The XPC translator speaks the Modicon Modbus
RTU Protocol as described in the Modicon Modbus Protocol Reference Guide, PI-MBUS-300 Rev.J, and
acts as a Modbus Master or Slave. Further details on the Modbus supported implementation are
described below.
Serial Transmission Mode: Supported?
RTU
Master or Slave (Slave RTU is the Default
Dipswitch setting)
ASCII Master or Slave
Communication
Types:
Baud
Rates:
Data
Bits:
Parity: Stop Bits:
2-wire EIA-485,
4-wire EIA-485,
or EIA-232
9600,
19200,
38400,
76800
8 None 1
Function Codes: Purpose: Used with Register
Numbers:
01 – Read Coil Status Read Discrete Outputs 00001 - 09999
02 – Read Input Status Read Discrete Inputs 10001 - 19999
03 – Read Holding
Registers Read Holding Registers 40001 - 49999
04 – Read Input
Registers Read Input Registers 30001 - 39999
05 – Force Single Coil Write Discrete Outputs
(single) 00001 - 09999
06 – Preset Single
Register Write Holding Registers
(single) 40001 - 49999
15 – Force Multiple
Coils Write Discrete Outputs 00001 - 09999
16 – Preset Multiple
Coils Write Holding Registers 40001 - 49999
