GATEWAY COMMUNICATIONS MANUAL

128

Table 10 AERCO BMS II & BCM Point Definitions - Continued

Equip.

Point Name

BAS Modbus

Data Addr

GF-124, GF-115C

Point Name

Reg.

Type

Modbus Data

Addr (Hex/Dec.)

Units (Range)

Modulex Blr with BCM - Cont.

06-Flow Sens Temp
(Flow Sensor
Temperature)

41003

Flow Sensor
Temperature

Holding

0x03EA / 1002

°F (14 to 212) (Value x 10)

07-Display Code

30001

Status & Error
Code
(C-more
compatible)

Input

0x0000 / 0

Enum
(2,8,10,18,23,32,38,42)
2 = Standby
8 = High Temp Switch
Open
10 = Low Gas Press
Switch Open
18 = Air Flow Switch Open
During Ignition
23 = Flame Loss During
Run
32 = Residual Flame
38 = Other Conditions Not
Listed
42 = Outlet (Flow) Temp
Sensor Fault

11-Error Code

40001

Error Code

Holding

0x0000 / 0

(0 to 0xFFFF)
LSB = Error Code
MSB = Id Code Of Fault
Device (0 = BMM#0, 7 =
BMM#7, 255 = BCM)

08-Unit Status

30002

Unit Status
(C-more
Compatible)

Input

0x0001 / 1

Enum (1,3,5)
1 = Standby (ready to run
but not fired)
3 = Fired
5 = Fault

09-Ret Flow Temp
(Return Flow
Temperature)

41004

Return Flow
Temperature

Holding

0x03EB / 1003

°F (32 to 212) (Value x 10)

NOTE

The points “Reg Outlet Temp” and “Net Direct Drive” are disabled as
default in the Modulex programs. This is suitable when a BMS II is
controlling the Modulex boilers. If there is no BMS II and the boiler is to be
directly controlled by the XPC, these points must be enabled usingthe
“AppLoader” program and the program cable.

IMPORTANT

All Modbus addresses specified in this manual are written generically in
hexadecimal/decimal format. However, many Building Automation Systems
utilize another form of addressing where:

• 40001 is added to the generic address for a Holding Register

address.

• 30001 is added to the generic address for an Input Register

address.

Check the addressing scheme being used by the BAS interfaced to the
XPC Gateway.
