GF-122 AERCO XPC GATEWAY
129
SECTION 29 PROTOCOL MAPPING TABLES
Tabular listings are provided for each of the AERCO equipment configurations in the order shown below:
PROTOCOL & EQUIPMENT CONFIGURATION PAGE
Modbus - To-BACnet Protocol Mapping
129
1 BMS/BMS II, 4 C-More Controlled Boilers 129
1 BMS/BMS II, 8 C-More Controlled Boilers 131
1 BMS/BMS II, 12 C-More Controlled Boilers 135
1 BMS II, 4 Modulex Boilers With BCMs 140
4 ECS Systems 142
Modbus-To-Johnson N2 Protocol Mapping
143
1 BMS/BMS II, 4 C-More Controlled Boilers 143
1 BMS/BMS II, 8 C-More Controlled Boilers
145
1 BMS/BMS II, 12 C-More Controlled Boilers
149
1 BMS II, 4 Modulex Boilers With BCMs
154
4 ECS Systems
156
Modbus-To-LonWorks Protocol Mapping
157
1 BMS/BMS II, 4 C-More Controlled Boilers
157
1 BMS/BMS II, 8 C-More Controlled Boilers
161
1 BMS/BMS II, 12 C-More Controlled Boilers
168
1 BMS II, 4 Modulex Boilers With BCMs
177
4 ECS Systems
180
