GF-122 AERCO XPC GATEWAY
155
Modbus-To-N2 Protocol Mapping
1 BMS II, 4 MLX Boilers
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled Type
N2
ID
BMS Addr 128
01-Fire Rate Out boilerstate_5 30005/128
 
data float 41
02-Header Set Temp effectsetpt_5 30006/128
 
data float 42
03-Net Header Set Temp setpt_5 40005/128

data float 43
04-Header Temp localsuptemp_5 30002/128
 
data float 44
05-Outside Air Temp localoatemp_5 30003/128
 
data float 45
06-Display Code dispcode_5 30011/128
 
data float 46
07-Num Boilers Fired blrfired_5 30008/128
 
data float 47
08-Num Boilers Online blronline_5 30009/128
 
data float 48
09-Last Blr Fired blrlast_5 30017/128
 
data float 49
18-Net Blr 1 Status blr9stat_5 30026/128
 
data float 58
19-Net Blr 2 Status blr10stat_5 30027/128
 
data float 59
20-Net Blr 3 Status blr11stat_5 30028/128
 
data float 60
21-Net Blr 4 Status blr12stat_5 30029/128
 
data float 61
Use Metric Conversion m101_5 binary out 9
Mlx Addr 1
01-Act Mod Lev boilerstate_1 41009/1
 
data float 62
02-Target Setpoint effectsetpt_1 41019/1
 
data float 63
03-Req Outlet Temp setpt_1 41005/1 data float 64
04-Net Direct Drive boilercmd_1 40002/1 data float 65
05-Mod Lev In boilerload_1 41201/1
 
data float 66
06-Flow Sens Temp localsuptemp_1 41003/1
 
data float 67
07-Display Code dispcode_1 30001/1
 
data float 68
11-Error Code errcode_1 40001/1
 
data float 69
08-Unit Status unitstat_1 30002/1
 
data float 150
09-Ret Flow Temp returntemp_1 41004/1
 
data float 151
Mlx Addr 2
01-Act Mod Lev boilerstate_2 41009/2
 
data float 153
02-Target Setpoint effectsetpt_2 41019/2
 
data float 154
03-Req Outlet Temp setpt_2 41005/2 data float 155
04-Net Direct Drive boilercmd_2 40002/2 data float 156
05-Mod Lev In boilerload_2 41201/2
 
data float 157
06-Flow Sens Temp localsuptemp_2 41003/2
 
data float 158
07-Display Code dispcode_2 30001/2
 
data float 159
11-Error Code errcode_2 40001/2
 
data float 160
08-Unit Status unitstat_2 30002/2
 
data float 161
09-Ret Flow Temp returntemp_2 41004/2
 
data float 162
Page 1 of 2
