Modbus-To-BACnet Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
BACnet
Type:ID
Blr Addr 1
01-Fire Rate Out boilerstate_1 30009/1
 
AV:26
02-Active Setpoint effectsetpt_1 30017/1
 
AV:27
03-Net Remote Setpt setpt_1 40001/1

AV:24
05-Fire Rate In boilerload_1 30018/1
 
AV:28
06-Outlet Temp localsuptemp_1 30003/1
 
AV:29
07-Display Code dispcode_1 30001/1
 
AV:22
08-Unit Status unitstat_1 30002/1
 
AV:23
09-Run Cycles runcycles_1 30012-30013/1
 
AV:42
10-Run Hours runhours_1 30014-30015/1
 
AV:43
Deg F or Deg C m114_1 BV:1
Use Temp Scaling m101_1 BV:2
Blr Addr 2
01-Fire Rate Out boilerstate_2 30009/2
 
AV:30
02-Active Setpoint effectsetpt_2 30017/2
 
AV:46
03-Net Remote Setpt setpt_2 40001/2

AV:47
05-Fire Rate In boilerload_2 30018/2
 
AV:50
06-Outlet Temp localsuptemp_2 30003/2
 
AV:51
07-Display Code dispcode_2 30001/2
 
AV:52
08-Unit Status unitstat_2 30002/2
 
AV:53
09-Run Cycles runcycles_2 30012-30013/2
 
AV:44
10-Run Hours runhours_2 30014-30015/2
 
AV:45
Deg F or Deg C m114_2 BV:3
Use Temp Scaling m101_2 BV:4
Blr Addr 3
01-Fire Rate Out boilerstate_3 30009/3
 
AV:54
02-Active Setpoint effectsetpt_3 30017/3
 
AV:55
03-Net Remote Setpt setpt_3 40001/3

AV:56
05-Fire Rate In boilerload_3 30018/3
 
AV:60
06-Outlet Temp localsuptemp_3 30003/3
 
AV:61
07-Display Code dispcode_3 30001/3
 
AV:62
08-Unit Status unitstat_3 30002/3
 
AV:63
09-Run Cycles runcycles_3 30012-30013/3
 
AV:58
10-Run Hours runhours_3 30014-30015/3
 
AV:59
Deg F or Deg C m114_3 BV:5
Use Temp Scaling m101_3 BV:6
