GATEWAY COMMUNICATIONS MANUAL
152
Modbus-To-N2 Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled Type
N2
ID
Blr Addr 7
01-Fire Rate Out boilerstate_7 30009/7
 
data float 61
02-Active Setpoint effectsetpt_7 30017/7
 
data float 62
03-Net Remote Setpt setpt_7 40001/7

data float 63
05-Fire Rate In boilerload_7 30018/7
 
data float 65
06-Outlet Temp localsuptemp_7 30003/7
 
data float 66
07-Display Code dispcode_7 30001/7
 
data float 67
08-Unit Status unitstat_7 30002/7
 
data float 68
09-Run Cycles runcycles_7 30012-30013/7
 
data float 69
10-Run Hours runhours_7 30014-30015/7
 
data float 70
Deg F or Deg C m114_7 binary out 13
Use Temp Scaling m101_7 binary out 14
Blr Addr 8
01-Fire Rate Out boilerstate_8 30009/8
 
data float 71
02-Active Setpoint effectsetpt_8 30017/8
 
data float 72
03-Net Remote Setpt setpt_8 40001/8

data float 73
05-Fire Rate In boilerload_8 30018/8
 
data float 75
06-Outlet Temp localsuptemp_8 30003/8
 
data float 76
07-Display Code dispcode_8 30001/8
 
data float 77
08-Unit Status unitstat_8 30002/8
 
data float 78
09-Run Cycles runcycles_8 30012-30013/8
 
data float 79
10-Run Hours runhours_8 30014-30015/8
 
data float 80
Deg F or Deg C m114_8 binary out 15
Use Temp Scaling m101_8 binary out 16
Blr Addr 9
01-Fire Rate Out boilerstate_9 30009/9
 
data float 81
02-Active Setpoint effectsetpt_9 30017/9
 
data float 82
03-Net Remote Setpt setpt_9 40001/9

data float 83
05-Fire Rate In boilerload_9 30018/9
 
data float 85
06-Outlet Temp localsuptemp_9 30003/9
 
data float 86
07-Display Code dispcode_9 30001/9
 
data float 87
08-Unit Status unitstat_9 30002/9
 
data float 88
09-Run Cycles runcycles_9 30012-30013/9
 
data float 89
10-Run Hours runhours_9 30014-30015/9
 
data float 90
Deg F or Deg C m114_9 binary out 17
Use Temp Scaling m101_9 binary out 18
Page 3 of 5
