Modbus-To-LonWorks Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
SNVT
# SNVT NAME SNVT
Element
# Direction Prio Auth Ack
08-Unit Status unitstat_2 30002/2
 
58 nvoUnitStat2
incremental
count (9)
0
Output (non-
polled)
09-Run Cycles runcycles_2 30012-30013/2
 
59 nvoRunCycles2 51 0
Output (non-
polled)
10-Run Hours runhours_2 30014-30015/2
 
60 nvoRunHours2 51 0
Output (non-
polled)
Deg F or Deg C m114_2 0
disabled NV
(0)
0
Input (non-
polling)
Use Temp Scaling m101_2 0
disabled NV
(0)
1
Input (non-
polling)
Blr Addr 3
01-Fire Rate Out boilerstate_3 30009/3
 
61 nvoBlrState3
incremental
count (9)
0
Output (non-
polled)
02-Active Setpoint effectsetpt_3 30017/3
 
62 nvoEffSetpt3
incremental
count (9)
0
Output (non-
polled)
03-Net Remote
Setpt
setpt_3 40001/3

63 nviSetpt3
incremental
count (9)
0
Input (non-
polling)
05-Fire Rate In boilerload_3 30018/3
 
65 nvoBlrLoad3
incremental
count (9)
0
Output (non-
polled)
06-Outlet Temp localsuptemp_3 30003/3
 
66 nvoLocSupTmp3
incremental
count (9)
0
Output (non-
polled)
07-Display Code dispcode_3 30001/3
 
67 nvoDispCode3
incremental
count (9)
0
Output (non-
polled)
08-Unit Status unitstat_3 30002/3
 
68 nvoUnitStat3
incremental
count (9)
0
Output (non-
polled)
09-Run Cycles runcycles_3 30012-30013/3
 
69 nvoRunCycles3 51 0
Output (non-
polled)
10-Run Hours runhours_3 30014-30015/3
 
70 nvoRunHours3 51 0
Output (non-
polled)
Deg F or Deg C m114_3 0
disabled NV
(0)
0
Input (non-
polling)
Use Temp Scaling m101_3 0
disabled NV
(0)
1
Input (non-
polling)
Blr Addr 4
01-Fire Rate Out boilerstate_4 30009/4
 
71 nvoBlrState4
incremental
count (9)
0
Output (non-
polled)
02-Active Setpoint effectsetpt_4 30017/4
 
72 nvoEffSetpt4
incremental
count (9)
0
Output (non-
polled)
03-Net Remote
Setpt
setpt_4 40001/4

73 nviSetpt4
incremental
count (9)
0
Input (non-
polling)
