GF-122 AERCO XPC GATEWAY
131
Modbus-To-BACnet Protocol Mapping
1 BMS/BMS II, 4 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled Type:ID
Blr Addr 4
01-Fire Rate Out boilerstate_4 30009/4
 
AV:70
02-Active Setpoint effectsetpt_4 30017/4
 
AV:71
03-Net Remote Setpt setpt_4 40001/4

AV:72
05-Fire Rate In boilerload_4 30018/4
 
AV:73
06-Outlet Temp localsuptemp_4 30003/4
 
AV:65
07-Display Code dispcode_4 30001/4
 
AV:66
08-Unit Status unitstat_4 30002/4
 
AV:67
09-Run Cycles runcycles_4 30012-30013/4
 
AV:68
10-Run Hours runhours_4 30014-30015/4
 
AV:69
Deg F or Deg C m114_4 BV:10
Use Temp Scaling m101_4 BV:11
BMS Addr 128
01-Fire Rate Out boilerstate_5 30005/128
 
AV:31
02-Header Set Temp effectsetpt_5 30006/128
 
AV:32
03-Net Header Set Temp setpt_5 40005/128

AV:33
04-Header Temp localsuptemp_5 30002/128
 
AV:34
05-Outside Air Temp localoatemp_5 30003/128
 
AV:35
06-Display Code dispcode_5 30011/128
 
AV:36
07-Num Boilers Fired blrfired_5 30008/128
 
AV:37
08-Num Boilers Online blronline_5 30009/128
 
AV:38
09-Last Blr Fired blrlast_5 30017/128
 
AV:39
10-Boiler 1 Status blr1stat_5 30018/128
 
AV:40
11-Boiler 2 Status blr2stat_5 30019/128
 
AV:41
12-Boiler 3 Status blr3stat_5 30020/128
 
AV:48
13-Boiler 4 Status blr4stat_5 30021/128
 
AV:1
14-Boiler 5 Status blr5stat_5 30022/128
 
AV:2
15-Boiler 6 Status blr6stat_5 30023/128
 
AV:3
16-Boiler 7 Status blr7stat_5 30024/128
 
AV:4
17-Boiler 8 Status blr8stat_5 30025/128
 
AV:5
18-Net Blr 1 Status blr9stat_5 30026/128
 
AV:6
19-Net Blr 2 Status blr10stat_5 30027/128
 
AV:7
20-Net Blr 3 Status blr11stat_5 30028/128
 
AV:8
21-Net Blr 4 Status blr12stat_5 30029/128
 
AV:9
Use Metric Conversion m101_5 BV:9
