AERCO XPC GATEWAY Communications - Manual (Page 175)

GF-122 AERCO XPC GATEWAY
175
Modbus-To-LonWorks Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
SNVT
# SNVT NAME SNVT
Element
# Direction Prio Auth Ack
05-Fire Rate In boilerload_9 30018/9
 
125 nvoBlrLoad9
incremental
count (9)
0
Output (non-
polled)
06-Outlet Temp localsuptemp_9 30003/9
 
126 nvoLocSupTmp9
incremental
count (9)
0
Output (non-
polled)
07-Display Code dispcode_9 30001/9
 
127 nvoDispCode9
incremental
count (9)
0
Output (non-
polled)
08-Unit Status unitstat_9 30002/9
 
128 nvoUnitStat9
incremental
count (9)
0
Output (non-
polled)
09-Run Cycles runcycles_9 30012-30013/9
 
129 nvoRunCycles9 51 0
Output (non-
polled)
10-Run Hours runhours_9 30014-30015/9
 
130 nvoRunHours9 51 0
Output (non-
polled)
Deg F or Deg C m114_9 0
incremental
count (9)
0
Output (non-
polled)
Use Temp Scaling m101_9 0
disabled NV
(0)
1
Input (non-
polling)
Blr Addr 10
01-Fire Rate Out boilerstate_10 30009/10
 
131 nvoBlrState10
incremental
count (9)
0
Output (non-
polled)
02-Active Setpoint effectsetpt_10 30017/10
 
132 nvoEffSetpt10
incremental
count (9)
0
Output (non-
polled)
03-Net Remote
Setpt
setpt_10 40001/10

133 nviSetpt10
incremental
count (9)
0
Input (non-
polling)
05-Fire Rate In boilerload_10 30018/10
 
135 nvoBlrLoad10
incremental
count (9)
0
Output (non-
polled)
06-Outlet Temp localsuptemp_10 30003/10
 
136 nvoLocSupTmp10
incremental
count (9)
0
Output (non-
polled)
07-Display Code dispcode_10 30001/10
 
137 nvoDispCode10
incremental
count (9)
0
Output (non-
polled)
08-Unit Status unitstat_10 30002/10
 
138 nvoUnitStat10
incremental
count (9)
0
Output (non-
polled)
09-Run Cycles runcycles_10 30012-30013/10
 
139 nvoRunCycles10 51 0
Output (non-
polled)
10-Run Hours runhours_10 30014-30015/10
 
140 nvoRunHours10 51 0
Output (non-
polled)
Deg F or Deg C m114_10 0
incremental
count (9)
0
Output (non-
polled)
Use Temp Scaling m101_10 0
disabled NV
(0)
1
Input (non-
polling)
Page 6 of 9
