GATEWAY COMMUNICATIONS MANUAL
178
Modbus-To-LonWorks Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
SNVT
# SNVT NAME SNVT
Element
# Direction Prio Auth Ack
BMS Addr 128 - Continued
17-Boiler 8 Status blr8stat_13 30025/128
 
28 nvoBlr8Stat
incremental
count (9)
0
Output (non-
polled)
18-Net Blr 1 Status blr9stat_13 30026/128
 
29 nvoNetBlr1Stat
incremental
count (9)
0
Output (non-
polled)
19-Net Blr 2 Status blr10stat_13 30027/128
 
30 nvoNetBlr2Stat
incremental
count (9)
0
Output (non-
polled)
20-Net Blr 3 Status blr11stat_13 30028/128
 
31 nvoNetBlr3Stat
incremental
count (9)
0
Output (non-
polled)
21-Net Blr 4 Status blr12stat_13 30029/128
 
32 nvoNetBlr4Stat
incremental
count (9)
0
Output (non-
polled)
22-Net Blr 5 Status blr13stat_13 30030/128
 
33 nvoNetBlr5Stat
incremental
count (9)
0
Output (non-
polled)
23-Net Blr 6 Status blr14stat_13 30031/128
 
34 nvoNetBlr6Stat
incremental
count (9)
0
Output (non-
polled)
24-Net Blr 7 Status blr15stat_13 30032/128
 
35 nvoNetBlr7Stat
incremental
count (9)
0
Output (non-
polled)
25-Net Blr 8 Status blr16stat_13 30033/128
 
36 nvoNetBlr8Stat
incremental
count (9)
0
Output (non-
polled)
26-Net Blr 9 Status blr17stat_13 30034/128
 
37 nvoNetBlr9Stat
incremental
count (9)
0
Output (non-
polled)
27-Net Blr 10
Status
blr18stat_13 30035/128
 
38 nvoNetBlr10Stat
incremental
count (9)
0
Output (non-
polled)
28-Net Blr 11
Status
blr19stat_13 30036/128
 
39 nvoNetBlr11Stat
incremental
count (9)
0
Output (non-
polled)
29-Net Blr 12
Status
blr20stat_13 30037/128
 
40 nvoNetBlr12Stat
incremental
count (9)
0
Output (non-
polled)
Use Metric
Conversion
m101_13 0
disabled NV
(0)
1
Input (non-
polling)
