AERCO XPC GATEWAY Communications - Manual (Page 147)

GF-122 AERCO XPC GATEWAY
147
Modbus-To-N2 Protocol Mapping
1 BMS/BMS II, 8 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled Type
N2
ID
Blr Addr 4
01-Fire Rate Out boilerstate_4 30009/4
 
data float 31
02-Active Setpoint effectsetpt_4 30017/4
 
data float 32
03-Net Remote Setpt setpt_4 40001/4

data float 33
05-Fire Rate In boilerload_4 30018/4
 
data float 35
06-Outlet Temp localsuptemp_4 30003/4
 
data float 36
07-Display Code dispcode_4 30001/4
 
data float 37
08-Unit Status unitstat_4 30002/4
 
data float 38
09-Run Cycles runcycles_4 30012-30013/4
 
data float 39
10-Run Hours runhours_4 30014-30015/4
 
data float 40
Deg F or Deg C m114_4 binary out 7
Use Temp Scaling m101_4 binary out 8
Blr Addr 5
01-Fire Rate Out boilerstate_5 30009/5
 
data float 41
02-Active Setpoint effectsetpt_5 30017/5
 
data float 42
03-Net Remote Setpt setpt_5 40001/5

data float 43
05-Fire Rate In boilerload_5 30018/5
 
data float 45
06-Outlet Temp localsuptemp_5 30003/5
 
data float 46
07-Display Code dispcode_5 30001/5
 
data float 47
08-Unit Status unitstat_5 30002/5
 
data float 48
09-Run Cycles runcycles_5 30012-30013/5
 
data float 49
10-Run Hours runhours_5 30014-30015/5
 
data float 50
Deg F or Deg C m114_5 binary out 9
Use Temp Scaling m101_5 binary out 10
Blr Addr 6
01-Fire Rate Out boilerstate_6 30009/6
 
data float 51
02-Active Setpoint effectsetpt_6 30017/6
 
data float 52
03-Net Remote Setpt setpt_6 40001/6

data float 53
05-Fire Rate In boilerload_6 30018/6
 
data float 55
06-Outlet Temp localsuptemp_6 30003/6
 
data float 56
07-Display Code dispcode_6 30001/6
 
data float 57
08-Unit Status unitstat_6 30002/6
 
data float 58
09-Run Cycles runcycles_6 30012-30013/6
 
data float 59
10-Run Hours runhours_6 30014-30015/6
 
data float 60
Deg F or Deg C m114_6 binary out 11
Use Temp Scaling m101_6 binary out 12
Page 2 of 4
