4-4
Con
trollin
g Mu
lti-
drop
Lin
k Mod
e
4
4-1 Multi-drop Link Mode
 N-410 Settings
Make the following settings in the AutoID Navigator.
1. Set multi-drop link to "Enabled" under "Main setting".
2. Register the connection types and ID numbers of the devices to be connected under "Slave
settings". Do not record these items if using manual polling.
3. Set the communication protocol under "Protocol setting".
4. Change the settings for baud rate, data bits and stop bit length to match those of the host
computer under "RS-232C settings". The RS-232C factory settings for the N-410 are as
follows.
5. Change the settings for baud rate, data bits and stop bit length to match those of the BL/SR/
RF Series device under "RS-485 settings".
* For more information on using AutoID Navigator and on N-410 settings, refer to the "AutoID
Navigator User's Manual".
 Host computer settings
Change the settings for baud rate, data bits and stop bit length to match the RS-232C side of the N-
410 settings.
Machine N-410 (RS-232C)
Baud rate 115200 bit/s
Data bits 8 bit
Parity Even
Stop bit length 1 bit
