Setting Commands for the N-410 Series
Trigger input settings (only available when using multi-head mode)
Send the following commands for trigger input on/off command character settings.
(Example) Changing the trigger input on command to S
or
S
S
WP5653 *S = 53h
Function
Command sent
Response
Explanation
Measurement method
settings
(Trigger mode)
Change
WP05n
OK
n = 0: Synchronize levels
1: One-shot synchronization
Confirm
RP05
05n
Settings for one-shot
synchronization measurement
Change
WP42nnn
OK
nnn = 001 to 255
(units: 100 ms)
Confirm
RP42
42nnn
Settings for trigger input at
input time
Change
WP04n
OK
n = 0: 2 ms
1: 10 ms
Confirm
RP04
04n
Trigger input polarity settings
Change
WP03n
OK
n = 0: Normal open point
1: Normal close point
Confirm
RP03
03n
Trigger input on command
character settings
Change WP56hhh...
OK
hhh... = Trigger input on command
(Up to 8 characters)
* Settings are specified in hexadecimal
(up to 16 characters).
Confirm
RP56
56hhh...
Trigger input off command
character settings
Change WP57hhh...
OK
hhh... = Trigger input off command
(Up to 8 characters)
* Settings are specified in hexadecimal
(up to 16 characters).
Confirm
RP57
57hhh...
Reference
CR
STX
ETX
