6-15
6-5 Setting Commands for the N-410 Series
S
er
ia
l Com
m
u
n
icat
ion
6
Setting Command
 Saving settings and closing setting initialization mode
 Main settings
Send the following commands for the read error codes.
(Example) Setting a read error code to BR
B R
WP554252 *B = 42h, R = 52h
Function Command sent Response Explanation
Save settings on the EEPROM SAVE OK
"6-5 Setting Commands for the
N-410 Series" (Page 6-13)
Initialize settings DFLT OK
This returns the settings to the factory
default
And saved them on the EEPROM
End setting mode SEND OK
"6-5 Setting Commands for the
N-410 Series" (Page 6-13)
Function Command sent Response Explanation
Operation mode
Change WP00n OK
n = 0: Multi-drop link mode
1: Multi-head mode
(BL Series, SR Series)
2: Multi-head mode
(RF Series)
Confirm RP00 00n
Trigger notification method
Change WP06n OK n = 0: Sequential notification
1: Interference suppression
2: Simultaneous notification
Confirm RP06 06n
Trigger ON time during
interference suppression
Change WP47nnn OK
nnn = 005 to 255
(units: 10 ms)
Confirm RP47 47nnn
nnn = 005 to 255
(units: 10 ms)
Read (tag) mode settings
Change WP12n OK n = 0: Single
1: Multi
Confirm RP12 12n
Trigger setting for sending
data
(only available for single
label) Change WP13n OK
n = 0: Send after read
1: Send after turning the trigger off
Confirm RP13 13n
Read error code settings
Change WP55hhh.. OK
hhh... = Read error code
(Up to 8 characters)
* Settings are specified in hexadecimal
(up to 16 characters).
* If nothing is specified, hhh... = FF
Confirm RP55 55hhh..
Reference
