Caution, Wiring the trigger input – KEYENCE N-410 User Manual
Page 28
2-6
Inst
allatio
2
2-2
N-410 Connections and Wiring
Be sure to use only 24 V DC power for this device. Usage of any other power
supply, including AC power, may damage this device.
Wiring the trigger input
When used in multi-head mode, the timing device should be connected to the N-410, not the BL/
SR/RF Series devices.
Caution
TIM COM
SG
+
+
Contact
or
non-contact
15 to 26V DC
+
+
Circuit diagram
Inter
nal circuit
TIM
COM
