Setting Commands for the N-410 Series
ID settings
RS-232C settings
Function
Command sent
Response
Explanation
Register ID numbers
(register one device at a
time)
Change
WIDmmn
OK
mm= 01 to 31: ID number
n = 0: Do not register anything
1: Register
Confirm
RIDmm
mmn
ID number serial registration
(All ID numbers up to the
specified number will be
registered)
Change WIDMAXmm
OK
mm= 01 to 31: ID number
*In a response, if mm = 99, no serial
numbers will be recorded.
Confirm
RIDMAXm
m
MAXmm
ID number batch registration
Change WIDAnnn...n
OK
n = 0: Do not register anything
1: Register
*n is ID numbers between from 1 to 31
in sequence
Confirm
RIDA
Annn...n
Register slave type
Change
WTPmmn
OK
mm = 01 to 31
n = 0: Nothing
1: N48+BL(SR)
2: N48+RF
3: NX+BL(SR)
4: NX+RF
Confirm
RTPmm
mmn
Batch register slave type
Change WTPAnnn...n
OK
n = 0: Do not register anything
1: Register
*n is ID numbers between from 1 to 31
in sequence
Confirm
RTPA
Annn...n
Function
Command sent
Response
Explanation
Baud rate settings
Change
WP35n
OK
n = 9: 115200 bit/s
8: 57600 bit/s
7: 38400 bit/s
5: 19200 bit/s
4: 9600 bit/s
Confirm
RP35
35n
Data bits settings
Change
WP30n
OK
n = 0: 7 bit
1: 8 bit
Confirm
RP30
30n
Parity type settings
Change
WP32n
OK
n = 0: None
1: Even
2: Odd
Confirm
RP32
32n
Stop bit length settings
Change
WP33n
OK
n = 0: 1 bit
1: 2 bit
Confirm
RP33
33n
RTS/CTS protocol settings
Change
WP22n
OK
n = 0: Do not activate
1: Activate
Confirm
RP22
22n
