Wired LAN Wired LAN Enable/Disable
Link Status Status of the Wired LAN Active/Inactive
MAC Address MAC Address XX:XX:XX:XX:XX:XX
TCP/IP Version TCP/IP Version IPv4/IPv6
IP Address IP Address XXX.XXX.XXX.XXX
Default Gateway Default Gateway XXX.XXX.XXX.XXX
Subnet Mask*1 Subnet Mask XXX.XXX.XXX.XXX
Subnet Prefix
Length*2
Subnet Prefix Length XXX
IPsec*3 IPsec setting Active
Security Protocol*3 Method of the Security Protocol ESP/ESP & AH/AH
Printer Name Printer name Printer name (Up to 15 characters)
Shared Memory Card Memory card sharing Enable/Disable
WSD WSD setting Enable/Disable
WSD Timeout Timeout 1/5/10/15/20 [min]
LLTD LLTD setting Enable/Disable
LPR Protocol LPR protocol setting Enable/Disable
Bonjour Bonjour setting Enable/Disable
Bonjour Service
Name Bonjour service name Bonjour service name (Up to 52
characters)
Bonjour LPR Service Bonjour LPR service
advertising Enable/Disable
("X" represents an alphanumeric character ranging from 0 to 9 and A to F.)
*1 Only when IPv4 is selected on IPv4/IPv6 setting, the status of the network is printed.
*2 Only when IPv6 is selected on IPv4/IPv6 setting, the status of the network is printed.
*3 Only when IPv6 is selected on IPv4/IPv6 setting and Active is selected on IPsec settings, the
status of the network is printed.
