Installation
8200SHB0199 4-12
4.1.4.2 Types 8221 to 8227
L
f
c1 e
h
m
n
l
k g
a
c2
c3
D
d1
d2
d3
d4
b
Z
FIG 4-9 Dimensions 8221 - 8227: Assembly with thermally separated power stage
3) With attachable fieldbus or I/O module:
Observe assembly depth and assembly space required for connection cables
[mm] a b c1 c2 c3 d1 d2 d3 d4 e 3) f g h
8221 / 8222 / 8223 280 379 28 140 252 41 141 238 338 250 90 6 9
8224 / 8225
8226 / 8227
Assembly cut-out Z [mm] Height Width k l m n
8221 / 8222 / 8223 338 –1 238 –1 20 –2 259 –2 20 –2 359 –2
8224 / 8225
8226 / 8227
