Page 48
Technical Data
8200SHB0199
3-16
3.4.7
Types 8244 to 8246
150 % overload
Type
8244
8245
8246
Order No.
EVF8244-E
EVF8245-E
EVF8246-E
Variant ”Cold Plate”
Type
8244-V003
8245-V003
8246-V003
Order No.
EVF8244-C-V003
EVF8245-C-V003
EVF8246-C-V003
Variant ”HVAC”
Type
8244-V020
8245-V020
8246-V020
Order No.
EVF8244-E-V020
EVF8245-E-V020
EVF8246-E-V020
Mains voltage
V
r
[V]
320 V -0 %
$ V
r
$ 528 V +0 %; 45 Hz ¡ 65 Hz á0 %
Alternative DC supply
V
DC
[V]
460 V -0%
$ V
DC
$ 740 V +0 %
Mains current
with mains filter/mains choke
without mains filter/mains choke
I
mains
[A]
I
mains
[A]
7.0
-
12.0
16.8
20.5
-
Data for mains operation with 3 AC / 400 V / 50 Hz/60 Hz ; 460 V
$ V
DC
$ 620 V or
3 AC / 480 V / 50 Hz/60 Hz ; 460 V
$ V
DC
$ 740 V
400 V
480 V
400 V
480 V
400 V
480 V
Motor power (4 pole ASM)
at 4 kHz/8 kHz*
P
r
[kW]
3.0
3.0
5.5
5.5
11.0
11.0
Motor power (4 pole ASM)
at 4 kHz/8 kHz*
P
r
[hp]
4.0
4.0
7.5
7.5
15.0
15.0
Output power U, V, W at 4 kHz/8 kHz*
S
r8
[kVA]
4.8
5.8
9.0
10.8
16.3
10.8
Output power + U
G
, -U
G
1)
P
DC
[kW]
2.0
2.5
0
0
0
0
Output
current
4 kHz*
I
r4
[A]
7.0
7.0
13.0
13.0
23.5
23.5
Output
current
8 kHz*
I
r8
[A]
7.0
7.0
13.0
13.0
23.5
23.5
12 kHz*
I
r12
[A]
6.3
6.3
11.7
11.7
20.0
19.1
16 kHz*
I
r16
[A]
5.6
5.6
10.4
10.4
16.5
15.7
Noise optimised 4 kHz*
4)
I
r4
[A]
7.0
6.6
13.0
12.3
23.5
22.1
Noise optimised 8 kHz*
4)
I
r8
[A]
6.0
5.6
11.1
10.4
20.0
18.8
Noise optimised 12 kHz*
I
r12
[A]
6.1
6.1
11.3
11.3
19.4
18.4
Noise optimised 16 kHz*
I
r16
[A]
5.2
5.2
9.7
9.7
15.2
14.6
Max.
output
4 kHz*
I
rmax8
[A]
10.5
10.5
19.5
19.5
35.0
33.5
Max.
output
current
8 kHz*
I
rmax8
[A]
10.5
10.5
19.5
19.5
35.0
33.5
current
for 60 s
2)
12 kHz*
I
rmax12
[A]
9.5
9.5
17.5
17.5
30.0
28.7
for 60 s
2)
16 kHz*
I
rmax16
[A]
8.4
8.4
15.6
15.6
24.6
23.6
Noise optimised 4 kHz*
4)
I
rmax4
[A]
10.5
8.4
19.5
15.6
35.5
28.2
Noise optimised 8 kHz*
4)
I
rmax8
[A]
7.8
7.8
14.5
14.5
22.9
21.8
Noise optimised 12 kHz*
I
rmax12
[A]
9.1
9.1
16.5
16.5
29.0
27.6
Noise optimised 16 kHz*
I
rmax16
[A]
7.8
7.8
14.5
14.5
22.9
21.8
Motor voltage
3)
V
M
[V]
0 - 3 x V
mains
/ 0 Hz
¡ 50 Hz, if required up to 480 Hz
Power loss (operation with I
rx
)
P
loss
[W]
150
210
360
Power derating
[%/K]
[%/m]
40
C < T
V
< 50
C: 2.5 %/K
1000 m a.m.s.l.
h $ 4000 m a.m.s.l.: 5 %/1000 m
