Technical Data

8200SHB0199

3-25

3.8

Dimensions

The controller dimensions depend on the mechanical installation (see chapter 4.1).

3.8.1

Analog plug-in module

Note!

Only controller of the series 8210, 8220 and 8240 HVAC (V020) can be equipped
with the analog plug-in module.

20
28

E1
E2

E3

E4

39

-

-

-

4.00 cm

0 - 10 V

Jumper

8279frnt_gb

0 - 20 mA

4.80 cm

3.90

cm

FIG 3-2

Dimensions of analog plug-in module

The changeover of the analog input between 0 V ... 10 V (factory setting) or
0 mA ... 20 mA (internal 500

W

load) is carried out via a jumper on the PCB.

The jumper can be accessed when removing the cover from the internal PCB.
