Configuration

8200SHB0199

7-47

7.5.11.6 Setpoint sum

Only “HVAC” controllers

Code

Name

Possible settings

IMPORTANT

Code

Name

Lenze

Choice

Info

IMPORTANT

C049* Additional setpoint

-480.00

{0.02 Hz}

480.00

Display only

Function

In controlled operation(C005 = -1-, -2-) the setpoint sum can be generated with

-

the signal of the analog input (terminal 8) or

-

the digital frequency at terminal E1 or

-

the function “Motor potentiometer” or

-

the process setpoint C046 (LECOM).

The additional setpoint is indicated under C049.

Special features

The display value of the parameter can be related to an application datum (C500, C501).
(see chapter 7.6.3)
