Technical Data
8200SHB0199 3-22
3.6.2 Single drives with 150 % overload
The table values are valid for the operation of 82XX controllers as single drives with
a matching motor and 150 % overload.
Type Mains input L1, N, PE / motor connection U, V, W, PE Type
Operation without mains filter/mains choke Operation with mains filter/mains choke
Fuse
F1, F2, F3 E.l.c.b. Cable cross-section 1) Fuse
F1, F2, F3 E.l.c.b. Cable cross-section 1)
VDE UL VDE mm 2 AWG VDE UL VDE mm 2 AWG
8201 M 10A - C 10A 1.5 15 M 10A - C 10A 1.5 15
8202 M 15A - C 16A 2.5 13 M 15A - C 16A 2.5
[1.5] 13
[15]
8203 M 20A - C 20A 4 11 M 15A - C 16A 2.5
[1.5] 13
[15]
8204 - - - - - M 20A - C 20A 4
[2.5] 11
[13]
Values in square brackets are valid for motor connection
Type Mains input L1, L2, L3, PE / motor connection U, V, W, PE Type
Operation without mains filter/mains choke Operation with mains filter/mains choke
Fuse
F1, F2, F3 E.l.c.b. Cable cross-section 1) Fuse
F1, F2, F3 E.l.c.b. Cable cross-section 1)
VDE UL VDE mm 2 AWG VDE UL VDE mm 2 AWG
8211 M 6A - B 6A 1 17 M 6A - B 6A 1 17
8212 M 10A - B 6A 1.5 15 M 6A - B 6A 1 17
8213 M 10A - B 10A 1.5 15 M 10A - B 10A 1.5 15
8214 - - - - - M 10A - B 10A 1.5 15
8215 M 16A - B 16A 2.5 13 M 16A - B 13A 2.5 13
8216 M 25A - B 25A 6 10 M 20A - B 20A 4 11
8217 M 32A - B 32A 6 10 M 25A - B 25A 6 10
8218 - - - - - M 32A - B 32A 6 10
Type Mains input L1, L2, L3, PE / motor connection U, V, W, PE Type
Operation without mains filter/mains choke Operation with mains filter/mains choke
Fuse
F1, F2, F3 E.l.c.b. Cable cross-section 1) Fuse
F1, F2, F3 E.l.c.b. Cable cross-section 1)
VDE UL VDE mm 2 AWG VDE UL VDE mm 2 AWG
8221 63A -- -- 16 5 M 35A 35A -- 10 7
8222 -- -- -- -- -- M 50A 50A -- 16 5
8223 -- -- -- -- -- M 80A 80A -- 25 3
8224 -- -- -- -- -- M 100A 100A -- 50 0
8225 -- -- -- -- -- M 125A 125A -- 70 2 / 0
8226 -- -- -- -- -- M 160A 175A -- 95 3 / 0
8227 -- -- -- -- -- M 200A 200A -- 120 4 / 0
8241 M 6A 5A B 6A 1 17 M 6A 5A B 6A 1 17
8242 M 6A 5A B 6A 1 17 M 6A 5A B 6A 1 17
8243 M 10A 10A B 10A 1.5 15 M 10A 10A B 10A 1.5 15
8244 -- -- -- -- -- M 10A 10A B 10A 1.5 15
8245 M 25A 25A B 25A 6 10 M 20A 20A B 20A 4 11
8246 -- -- -- -- -- M 32A 25A B 32A 6 10
1) Observe national and regional regulations (e.g. VDE/EVU)!
