Lenze 8200 Frequency inverters - Manual (Page 229)

Configuration
8200SHB0199 7-92
Code IMPORTANT Possible settings Name Code IMPORTANT
Info Choice Lenze
Name
C115 ¤ Priority mask digital
inputs
-0- E4 E3 E2 E1
-0- 0 0 0 0
-1- 0 0 0 1
-2- 0 0 1 0
-3- 0 0 1 1
-4- 0 1 0 0
-5- 0 1 0 1
-6- 0 1 1 0
-7- 0 1 1 1
-8- 1 0 0 0
-9- 1 0 0 1
-10- 1 0 1 0
-11- 1 0 1 1
-12- 1 1 0 0
-13- 1 1 0 1
-14- 1 1 1 0
-15- 1 1 1 1
Page 7-53 0: Function Ex
depends on C001
1: Function Ex is
independent of C001
- Ctrl. inhibit and TRIP
reset always have
first priority.
- With -0- also TRIP
set and QSP have
priority.
C117 ¤ Function relay K2
-0- -0- Ready for operation
-1- TRIP fault message
-2- Motor is running
-3- Motor is running / CW rotation
-4- Motor is running / CCW rotation
-5- Field frequency f
d
= 0
-6- f
dset
reached
-7- Q
min
reached
-8- I
max
reached
-9- Overtemperature ( J
max
-10 •C)
-10- TRIP or Q
min
or IMP
Page 7-65 ff
822X/824X -11- PTC warning
-12- Apparent motor current
(C054) < threshold C156
-13- Apparent motor current
(C054) < current threshold C156
and f
d
> Q
min
threshold (C017)
-14- Apparent motor current
(C054) < threshold C156 and input
of ramp function generator =
output of ramp function generator
822X/824X -15- Warning motor phase failure
-16- f
d
(C050) < f
dmin
(C010)
C119 ¤ Function PTC
822X/824X -0- -0- PTC input not active
-1- PTC input active, TRIP and pulse
inhibit will be set
-2- PTC input active
Warning
Page 7-72
C120 I 2 kt switch-off Page 7-71 C120
822X/824X 0 0 {1 %} 100 If C120 = 0, the
function is not active
