Preface and general information

8200SHB0199

1-2

Accessory kit

820X

821X

821X-V003

8221
8222
8223

8224
8225

8226
8227

8221-V003
8222-V003

824X

824X-V003

7-pole socket connectors for
control cables

2

2

2

2

2

2

2

2

2

3-pole socket connectors for
relay output K2

-

-

-

1

1

1

1

1

1

Fixing rails

2

2

2

-

-

-

-

2

-

Fixing units incl. screws for
fixing the inverter to the
housing

-

-

-

4

4

-

-

-

-

PG diaphragm gland 21

-

-

-

1

1

1

1

-

-

Screen sheet for control
cables incl. fixing screw

-

-

-

1

1

1

1

1

1

Screen sheet for motor cable
incl. two fixing screws

-

-

-

1

1

1

1

1

1

Hexagon nuts incl. washers
and spring-lock washers for
the electrical connection of
the power stage

-

-

-

8 M6

8 M8

8 M10

8 M6

-

-

Heat-conducting paste

-

-

1 tube

-

-

-

1 tube

-

1 tube

Gasket

-

-

1

-

-

-

1

-

1

Tightening frame

-

-

1

-

-

-

2

-

2
