2 priority mask for digital inputs, Priority mask for digital inputs, Configuration – Lenze 8200 Frequency inverters User Manual
Page 190: Only “hvac” controllers
Configuration
8200SHB0199
7-53
7.5.14.2 Priority mask for digital inputs
Only “HVAC” controllers
Code
Name
Possible settings
IMPORTANT
Lenze
Choice
Info
C115
¤ Priority mask digital
inputs
-0-
E4
E3
E2
E1
-0-
0
0
0
0
-1-
0
0
0
1
-2-
0
0
1
0
-3-
0
0
1
1
-4-
0
1
0
0
-5-
0
1
0
1
-6-
0
1
1
0
-7-
0
1
1
1
-8-
1
0
0
0
-9-
1
0
0
1
-10-
1
0
1
0
-11-
1
0
1
1
-12-
1
1
0
0
-13-
1
1
0
1
-14-
1
1
1
0
-15-
1
1
1
1
0: Function Ex
depends on C001
1: Function Ex is
independent of C001
Function
-
Independently of the operating mode C001 = -3- (control via LECOM), it is possible to activate
additional digital inputs.
- It is now possible to use additional control functions via terminals E1 ... E4. The signals are
assigned by means of an OR link.
-
C115 = -0- is always active with terminal configuration (C007) with manual/remote changeover.
Adjustment
Example
The DC injection brake is to be activated via terminal 3:
-
Operating mode C001 = -3- (control via LECOM).
-
Terminal configuration C007 = -0-.
Solution:
-
Set the priority mask C115 = -4-
- The DC injection brake can now be activated via terminal E3.
Important
-
Controller inhibit and TRIP reset always have priority.
-
With C115 = -0-, also TRIP set and QSP have priority.
