Technical Data
8200SHB0199 3-17
150 % overload Type 8244 8245 8246
Order No. EVF8244-E EVF8245-E EVF8246-E
Variant ”Cold Plate” Type 8244-V003 8245-V003 8246-V003
Order No. EVF8244-C-V003 EVF8245-C-V003 EVF8246-C-V003
Variant ”HVAC” Type 8244-V020 8245-V020 8246-V020
Order No. EVF8244-E-V020 EVF8245-E-V020 EVF8246-E-V020
Field
frequency Resolution Absolute 0.02 Hz Field
frequency Digital setpoint selection
Accuracy á0.05 Hz
Analog setpoint selection Linearity á0.5 %(max. selected signal level: 5 V or 10 V) Analog setpoint selection
Temperature
sensitivity 0 ¡ 40 •C: +0.4 %
Offset á0 %
Weight
”Cold Plate” without heat sink m [kg] 5.0 7.5 7.5
Printed in bold Data for the operation with factory setting and a chopper frequency of 8 kHz.
1) This power can be additionally obtained when operating a matching motor
2) The currents apply to a periodical load cycle with 1 minute overcurrent with the current mentioned here and
2 minutes base load with 75 % I
rx
.
3) With mains choke/mains filter: max. output voltage = approx. 96 % of the mains voltage
4) Only with variant “HVAC”
* Chopper frequency of the inverter
