Technical Data
8200SHB0199
3-2
3.2
Features
820X
821X
822X
824X
Compact design
/
/
/
/
Load capacity of up to 150 % I
r
for 1 min
/
/
/
/
Inverter outputs are protected against short circuit
/
/
/
/
Earth-fault check at mains connection
/
/
/
/
Chopper frequency 9.2 kHz
/
Chopper frequency selectable: 4 kHz, 8 kHz, 12 kHz, 16 kHz
/
/
/
V/f-characteristic control with constant V
min
boost or auto boost
/
Motor-current control or V/f-characteristic control selectable
/
/
/
Mains-voltage compensation
/
/
/
/
Slip compensation
/
/
/
/
Adjustable current limitation with V/f-override
/
/
/
/
PWM converter with IGBT-power stages
/
/
/
/
DC-bus connection and brake-chopper connection
/
/
/
/
Isolated analog input and output
/
/
/
/
Relay outputs (change-over contact)
1
1
2
2
PLC-compatible digital outputs (I/O module 8275)
3 (option)
3 (option)
3 (option)
3 (option)
Isolated digital inputs with programmable functions
4
4
4
4
Up to 3 JOG frequencies per parameter set
/
/
/
/
DC-injection brake
/
/
/
/
TRIP set and TRIP reset function
/
/
/
/
Motor potentiometer
/
/
/
/
Output frequency up to 240 Hz / 480 Hz
/
Output frequency up to 480 Hz
/
/
/
Flying restart circuit
/
/
/
/
2 parameter sets
/
/
/
/
Elapsed time meter
/
/
/
/
Assembly with thermal separation of the power stage
as from
8215E
/
/
Temperature-dependent blower activation
/
/
PTC monitoring of the motor by integrated evaluation
option
option
/
/
Process and speed controller
/*
/*
/*
Setpoint summation
/*
/*
/*
Level inversion for digital inputs
/*
/*
/*
Priority for digital inputs
/*
/*
/*
Manual/remote changeover (H/Re)
/*
/*
/*
Belt monitoring
/*
/*
/*
Selection of an inverse analog setpoint
/*
/*
/*
Limit frequencies
/*
/*
/*
Ramp function generator S-shape
/*
/*
/*
Motor phase failure detection
/*
/*
