Configuration
8200SHB0199 7-73
7.7.4 Motor-phase failure detection
Only series “HVAC”
Setting range 821X: not possible
Setting range 822X/824X:
Code Name Possible settings IMPORTANT
Lenze Choice Info
C597* ¤ Activation of
motor-phase failure
detection
-0- -0- Inactive
-1- TRIP
-2- Warning
C599 Current limit for
motor-phase failure
detection
5 1 {1 %} 50
Function If the function is activated under C597, the controller monitors the motor phases for failure. The
current limit value (C599) defines the threshold when a motor phase failure is indicated. The value
set under C599 corresponds to the percentage of the rated controller current [I
r
].
Activation - C597 = -0- function not active
- C597 = -1- fault message TRIP
- C597 = -2- warning message
Fault indication - 8201BB operating module:
- TRIP:
LP1
- Warning: LP1
- Fieldbus:
- TRIP:
32
- Warning: 182
Important C597 and C599 are only stored in parameter set 1.
