Technical Data
8200SHB0199
3-18
3.5
Rated data
(Operation with 120 % overload)
3.5.1
Operating conditions
-
Applications:
- Pumps with square characteristic
- Fans
-
Operation only
- with mains filter or mains choke,
- with mains voltage 3 AC / 400 V / 50 Hz/60 Hz,
- 821X with chopper frequencies
{
8 kHz,
- 822X/824X with chopper frequencies = 4 kHz (chopper
frequencies
{
16 kHz possible, load-dependent derating).
-
Automatic chopper-frequency reduction to 4 kHz.
-
Adapt mains-side accessories to the increased mains current:
- Fuses and cable cross-sections, see chapter 3.6.3.
- For data of other components, see ”Accessories”.
3.5.2
Types 821X
120 % overload
Type
8211
8212
8213
8214
8215
8216
8217
8218
Rated mains current
with mains filter/mains choke
I
r
[A]
3.0
3.9
7.0
7.0
12.0
12.0
20.5
20.5
Data for mains operation with 3 AC / 400 V / 50 Hz/60 Hz ; 450 V
$ V
DC
$ 650 V
Motor power (4 pole ASM)
P
r
[kW]
1.1
1.5
3.0
3.0
5.5
5.5
11.0
11.0
Motor power (4 pole ASM)
P
r
[hp]
1.5
2.0
4.0
4.0
7.5
7.5
15.0
15.0
Output power U, V, W
S
r
[kVA]
2.1
2.7
5.2
5.2
9.0
9.0
16.3
16.3
Output
current
4 kHz
I
r
[A]
3.0
3.9
7.3
7.3
13.0
13.0
23.5
23.5
Output
current
8 kHz
*1)
I
r
[A]
3.0
3.9
7.3
7.3
13.0
13.0
23.5
23.5
Max.
output
current
4 kHz
I
Nm
[A]
3.6
5.9
8.3
11.0
14.1
19.5
24.8
35.3
output
current
for 60 s
2)
8 kHz
*1)
I
Nm
[A]
3.6
5.9
8.3
11.0
14.1
19.5
24.8
35.3
Power loss
P
loss
[W]
65
75
100
100
200
200
400
400
1)
Only with variant “HVAC”
*
No dyn. chopper frequency derating of the inverter
All other data, see chapter 3.4.2 and chapter 3.4.3.
