Configuration
8200SHB0199
7-91
Code
IMPORTANT
Possible settings
Name
Code
IMPORTANT
Info
Choice
Lenze
Name
C111
¤ Monitor signal
-0-
-0-
Field frequency
-1-
Unit load
-2-
Motor current
-3-
DC-bus voltage
-4-
Motor power
-5-
Motor voltage
-6-
Analog output 1/f
d
(1/C050)
-7-
Field frequency of
f
dmin
(C010) ... f
dmax
(C011)
-8-
Actual PID controller value
Page 7-69
Selection -9- ... -25-
corresponds to the
relay output functions
C008 and C117:
-
LOW = 0 V
-
HIGH = 10 V
-9-
Ready for operation
-10-
TRIP fault message
-11-
Motor is running
-12-
Motor is running / CW rotation
-13-
Motor is running / CCW rotation
-14-
Field frequency f
d
= 0
-15-
f
dset
reached
-16-
Q
min
reached
-17-
I
max
reached
-18-
Overtemperature (
Ô
max
-10
)
-19-
TRIP, Q
min
or IMP set
822X/824X
-20-
PTC warning
-21-
Apparent motor current
(C054) < current threshold (C156)
-22-
Apparent motor current
(C054) < current threshold (C156)
and f
d
> Q
min
threshold
-23-
Apparent motor current
(C054) < threshold (C156) and
input of ramp function generator =
output of ramp function generator
822X/824X
-24-
Warning motor phase failure
-25-
f
d
(C050) < f
dmin
(C010)
C114
¤ Signal level digital
inputs
-0-
E4
E3
E2
E1
-0-
0
0
0
0
-1-
0
0
0
1
-2-
0
0
1
0
-3-
0
0
1
1
-4-
0
1
0
0
-5-
0
1
0
1
-6-
0
1
1
0
-7-
0
1
1
1
-8-
1
0
0
0
-9-
1
0
0
1
-10-
1
0
1
0
-11-
1
0
1
1
-12-
1
1
0
0
-13-
1
1
0
1
-14-
1
1
1
0
-15-
1
1
1
1
Page 7-52
0: Ex is not inverted
1: Ex is inverted
