Configuration
8200SHB0199 7-79
Code IMPORTANT Possible settings Name Code IMPORTANT
Info Choice Lenze
Name
C013 Deceleration time T
if
Page 7-16,
7-55
820X 5.00 0.00 {0.05 s} 999.00
821X/822X/
824X
5.00 0.00 {0.02 s} 999.00
C014 ¤ Control mode Page 7-19,
7-22, 7-24
820X -0- -0- Linear characteristic V f
d
with
auto boost
-1- Square characteristic V f
d
2 with
auto boost
-2- Linear characteristic V f
d
with
constant V
min
boost
-3- Square characteristic V f
d
2 with
constant V
min
boost
821X/822X/
824X
-4- -4- Motor-current control
C015 V/f-rated frequency Page 7-22 C015
820X 50.00 30.00 {0.05 Hz} 960.00
821X/822X/
824X
50.00 7.50 {0.02 Hz} 960.00
C016 V
min
setting Page 7-24 C016
820X * 0.00 {0.02 %} 40.00 *depends on the unit
821X/822X/
824X
0.00 0.00 {0.02 %} 40.00
C017 œ Threshold Q
min
0.00 0.00 {0.02 Hz} 480.00 Page 7-65
C018 ¤ Chopper frequency Page 7-29 C018 ¤
821X/822X/824X -1- -0- 4 kHz power-loss optimised
-1- 8 kHz power-loss optimised
-2- 12 kHz power-loss optimised
-3- 16 kHz power-loss optimised
-4- 12 kHz noise optimised
-5- 16 kHz noise optimised
C019 œ Threshold
auto DC brake
Page 7-56
821X/822X/824X 0.10 0.10 {0.02 Hz} 5.00
C021 Slip compensation Page 7-28 * If C014 = -2-, -3-,
controller dependent
820X 0.0* 0.0 {0.1 %} 12.0
821X/822X/
824X
0.0* 0.0 {0.1 %} 20.0
C022 I
max
limit
(motor mode)
150 30 {1 %} 150 Page 7-17
C023 I
max
limit
(generator mode)
80 30 {1 %} 110 Page 7-17 The current-limit
controller for operation
in generator mode is
822X/824X 80 30 {1 %} 150 As of software
1.6
controller for operation
in generator mode is
not active at 30 %.
C034 ¤ Master current -0- -0- 0 to 20 mA /
0 to 5 V / 0 to 10 V
-1- 4 to 20 mA
Page 7-40
