Commissioning
8200SHB0199
5-20
Functions used
-
Internal PID controller for pressure control.
- Regular control, setpoint selection via fieldbus with feedback via analog
channel terminal 8.
-
Networking via fieldbus (e.g. via plug-in module 2102).
-
Manual/remote changeover (H/Re).
- Setpoint selection change via key ( E1 = DOWN / E2 = UP).
-
Process setpoint selection (e.g. pressure [p]) via inverter JOG value.
-
Electrical controller inhibit (Ctrl. enable).
Code settings:
Code
Name
Possible settings
IMPORTANT
Code
Name
Lenze
Choice
Info
IMPORTANT
C001 Operating mode
-0-
-3-
Setpoint selection - control,
parameter setting via LECOM
C005 Configuration
-0-
-7-
Controlled operation, with
analog feedback via term. 8
C007 Terminal configuration
-0-
-26-
Motor potentiometer, JOG,
H/Re
C037 JOG value 1
20.00
16.67 HzFixed reduction to 1/3 of the
rated pressure
C051 Actual PID controller value
Only display of actual
pressure
C070 Gain PID controller
1.00
0.02 ... 0.1
Adaptation to process
C071 Integral action time PID
controller
100
0.2 ... 1 s
Adaptation to process
C072 Differential component PID
controller
0.0
0.0
Inactive
C074 Influence PID controller
0.0
100.0 %
C111
¤ Monitor signal
-0-
-8-
Actual PID controller value
C238 Frequency precontrol
-1-
-0-
No precontrol
C239 Frequency setting range
-0-
-1-
Unipolar
Direction of rotation
cannot be changed via
the process controller
-
All other parameters are based on the factory setting.
-
Set the rated motor data under C088 (rated motor current) and C091 (motor cos
j) depending on the motor
connected.
-
In addition to the setpoint input via fieldbus, the pressure setpoint can also be selected via the 8201BB keypad
(installation up to max. 10 m away from the controller) or via an analog input signal (using the 8274 plug-in
module).
Note!
-
For more detailed information on the process controller see chapter 7.5.10.
-
Calibration of the setpoints and actual values to the application datum under
C500 and C501.
(See chapter 5.4.2.4).
