Configuration
8200SHB0199 7-50
7.5.14 Function of the inputs to be configured block by block
C007 E1 E2 E3 E4
-0- JOG 1, JOG 2, JOG 3 DC injection brake CW/CCW
-1- JOG 1, JOG 2, JOG 3 PAR CW/CCW
-2- JOG 1, JOG 2, JOG 3 QSP CW/CCW
-3- JOG 1 DC injection brake PAR CW/CCW
-4- JOG 1 PAR QSP CW/CCW
-5- JOG 1 TRIP set DC injection brake CW/CCW
-6- JOG 1 TRIP set PAR CW/CCW
-7- TRIP set DC injection brake PAR CW/CCW
-8- TRIP set PAR QSP CW/CCW
-9- JOG 1 TRIP set QSP CW/CCW
-10- DOWN UP TRIP set CW/CCW
-11- DOWN UP DC injection brake CW/CCW
-12- DOWN UP PAR CW/CCW
-13- DOWN UP QSP CW/CCW
-14- JOG 1 DC injection brake CW/QSP CCW/QSP
-15- JOG 1 PAR CW/QSP CCW/QSP
-16- JOG 1, JOG 2, JOG 3 CW/QSP CCW/QSP
-17- DC injection brake PAR CW/QSP CCW/QSP
-18- TRIP set PAR CW/QSP CCW/QSP
-19- TRIP set DC injection brake CW/QSP CCW/QSP
-20- JOG 1 TRIP set CW/QSP CCW/QSP
-21- DOWN UP CW/QSP CCW/QSP
-22- JOG 1 UP CW/QSP CCW/QSP
only
series “HVAC”
-23- DOWN UP CW/CCW H/RE only
series “HVAC”
-24- DOWN UP PAR H/RE
-25- DOWN UP DC injection brake H/RE
-26- DOWN UP JOG1 H/RE
-27- DOWN UP TRIP set H/RE
-28- D/F I-OFF JOG 1, JOG 2, JOG 3
-29- D/F I-OFF DC injection brake JOG 1
-30- D/F I-OFF QSP JOG 1
-31- D/F I-OFF QSP DC injection brake
-32- D/F I-OFF QSP TRIP set
-33- D/F I-OFF PAR QSP
-34- D/F I-OFF CW/QSP CCW/QSP
-35- D/F PAR JOG 1, JOG 2, JOG 3
-36- D/F PAR QSP CCW/QSP
-37- D/F PAR QSP CCW/QSP
-38- D/F TRIP set PAR CCW/QSP
-39- D/F TRIP set JOG 1, JOG 2, JOG 3
