Technical Data
8200SHB0199 3-21
3.6 Fuses and cable cross-sections
3.6.1 Operation of controllers in UL-approved systems
-
Use only UL-approved fuses and fuse holders:
- 500 V to 600 V in the mains input (AC, F1 ... F3),
- 700 V in the voltage DC bus (DC, F4/F5),
- Activation characteristic ”H” or ”K5”.
-
Only use UL-approved cables
Note!
-
UL-approved fuses and fuse holder are produced and sold by e.g.
Gemballa Electronics GmbH in Kaltenkirchen, Germany.
-
DC fuses as part of the Lenze accessories are UL approved.
3.6.1.1 Protection of the motor cables
-
For functional reasons, the motor cables need not to be protected by fuses
if you only connect a motor per controller.
-
If you want to drive several motors in parallel connected to a controller, an
individual cable protection is required when reducing the cable
cross-section.
-
Refer to the data listed in ”Operation with mains filter/mains choke”
