Technical Data
8200SHB0199
3-5
3.4
Rated data
(Operation with 150 % overload)
3.4.1
Types 8201 to 8204
150 % overload
Type
8201
8202
8203
8204
Order No.
EVF8201-E
EVF8202-E
EVF8203-E
EVF8204-E
Variant ”reduced assembly
depth”
Type
8202-V002
Variant ”reduced assembly
depth”
Order No.
EVF8202-E- V002
Mains voltage
V
r
[V]
190 V -0 %
$ V
r
$ 260 V +0 %; 45 Hz ¡ 65 Hz á0%
Alternative DC supply
V
DC
[V]
270 V -0 %
$ V
DC
$ 360 V +0 %
Mains current
4)
with mains filter/mains choke
without mains filter/mains choke
I
mains
[A]
4.2
5.0
7.5
9.0
12.5
15.0
17.0
-
Data for mains operation with 1 AC / 230 V / 50 Hz/60 Hz; 270 V
$ V
DC
$ 275 V
Motor power (4 pole ASM)
at 9.2 kHz*
P
r
[kW]
0.37
0.75
1.5
2.2
Motor power (4 pole ASM)
at 9.2 kHz*
P
r
[hp]
0.5
1.0
2.0
2.9
Output power U, V, W at 9.2 kHz*
S
r9.2
[kVA]
1.0
1.5
2.7
3.6
Output power + U
G
, -U
G
1)
P
DC
[kW]
0.0
0.0
0.0
0.0
Output current
I
r
[A]
2.6
4.0
7.0
9.5
Max. output current for 60 s
2)
I
rmax
[A]
3.9
6.0
10.5
14.2
Motor voltage
3)
V
M
[V]
0 - 3 x V
mains
/ 0 Hz
¡ 50 Hz, if required up to 240 Hz
Power loss (operation with I
r
)
P
loss
[W]
30
50
70
100
Power derating
[%/K]
[%/m]
40
C < T
V
< 50
C: 2.5 %/K
1000 m a.m.s.l.
h $ 4000 m a.m.s.l.: 5 %/1000 m
Field
frequency
Resolution
Absolute
0.05 Hz
Field
frequency
Digital setpoint
selection
Accuracy
á0.05 Hz
Analog setpoint
selection
Linearity
á0.5 %(max. selected signal level, 5 V or 10 V)
Analog setpoint
selection
Temperature
sensitivity
0
¡ 40 C: +0.4 %
Offset
á0.3 %
Weight
m [kg]
1.0
1.3
Variant 1.0
2.2
2.2
1)
This power can be additionally obtained when operating a matching motor
2)
The currents apply to a periodical load cycle with 1 minute overcurrent with the current mentioned here and
2 minutes base load with 75 % I
r
.
3)
With mains choke/mains filter: max. output voltage = approx. 96 % of the mains voltage
4)
Observe the N-conduction load when having a symmetrical mains distribution! (See electrical installation)
*
Chopper frequency of the inverter
