Configuration
8200SHB0199 7-87
Code IMPORTANT Possible settings Name Code IMPORTANT
Info Choice Lenze
Name
C007 ¤
(continued)
Terminal
configuration -0- E4 E3 E2 E1
-11- CW/CCW GSB UP DOWN
-12- CW/CCW PAR UP DOWN
-13- CW/CCW QSP UP DOWN
-14- CCW/QSPCW/QSP GSB JOG1
-15- CCW/QSPCW/QSP PAR JOG1
-16- CCW/QSPCW/QSP JOG1/2/3
-17- CCW/QSPCW/QSP PAR GSB
-18- CCW/QSPCW/QSP PAR TRIP set
-19- CCW/QSPCW/QSP GSB TRIP set
-20- CCW/QSPCW/QSPTRIP set JOG1
-21- CCW/QSPCW/QSP UP DOWN
-22- CCW/QSPCW/QSP UP JOG1
-23- H/Re CW/CCW UP DOWN
-24- H/Re PAR UP DOWN
-25- H/Re GSB UP DOWN
-26- H/Re JOG1 UP DOWN
-27- H/Re TRIP set UP DOWN
-28- JOG1/2/3 I-OFF D/F
-29- JOG1 GSB I-OFF D/F
-30- JOG1 QSP I-OFF D/F
-31- GSB QSP I-OFF D/F
-32- TRIP set QSP I-OFF D/F
-33- QSP PAR I-OFF D/F
-34- CCW/QSPCW/QSP I-OFF D/F
-35- JOG1/2/3 PAR D/F
-36- GSB QSP PAR D/F
-37- JOG1 QSP PAR D/F
-38- JOG1 PAR TRIP set D/F
-39- JOG1/2/3 TRIP set D/F
-40- JOG1 QSP TRIP set D/F
-41- JOG1 GSB TRIP set D/F
-42- QSP GSB TRIP set D/F
-43- CW/CCW QSP TRIP set D/F
-44- UP DOWN PAR D/F
-45- CW/CCW QSP PAR D/F
-46- H/Re PAR QSP JOG1
-47- CW/QSPCCW/QSP H/Re JOG1
-48- INFL_0 GSB I-OFF D/F
-49- INFL_0 JOG1 QSP D/F
-50- INFL_0 JOG1 I-OFF D/F
-51- GSB PAR I-OFF D/F
- TRIP Set =
External fault
- UP/DOWN =
Motor potentiometer
functions
- H/Re =
Manual/remote
changeover
- I-OFF =
Reset of the
I-component of the
PID controller
- D/F =
Digital frequency
input 0 - 10 kHz
- EINFL_0 =
Set the influence of
the PID controller to
0
For parameter set
changeover via
terminals, the
corresponding
terminal must be
assigned with PAR in
both parameter sets.
