Lenze 8200 Frequency inverters - Manual (Page 225)

Configuration
8200SHB0199 7-88
Code IMPORTANT Possible settings Name Code IMPORTANT
Info Choice Lenze
Name
C008 ¤ Function relay K1 -1- -0- Ready for operation
-1- TRIP fault message
-2- Motor is running
-3- Motor is running / CW rotation
-4- Motor is running / CCW rotation
-5- Field frequency f
d
= 0
-6- f
dset
reached
-7- Q
min
reached
-8- I
max
reached
-9- Overtemperature ( J
max
-10 •C)
-10- TRIP or Q
min
or IMP
Page 7-65
822X/824X -11- PTC warning
-12- Apparent motor current
(C054) < threshold C156
-13- Apparent motor current
(C054) < current threshold C156
and f
d
> Q
min
threshold (C017)
-14- Apparent motor current
(C054) < threshold C156 and input
of ramp function generator =
output of ramp function generator
822X/824X -15- Warning motor phase failure
-16- f
d
(C050) < f
dmin
(C010)
C009* ¤ Device address 1 1 {1} 99 Only for LECOM
applications
C010 œ Minimum field
frequency
0.00 0.00 {0.02 Hz} 480.00 Page 7-15
C011 œ Maximum field
frequency
50.00 7.50 {0.02 Hz} 480.00 Page 7-15
C012 Acceleration time T
ir
5.00 0.00 {0.02 s} 1300.00 Page 7-16
C013 Deceleration time T
if
5.00 0.00 {0.02 s} 1300.00 Page 7-16,
7-55
C014 ¤ Control mode -4- -2- Linear characteristic V f
d
with
constant V
min
boost
-3- Square characteristic V f
d
2 with
Page 7-19,
7-22, 7-24
-3- Square characteristic V f
d
2 with
constant V
min
boost constant V
min
boost
-4- Motor-current control
C015 V/f rated frequency 50.00 7.50 {0.02 Hz} 960.00 Page 7-22
C016 V
min
setting * 0.00 {0.02 %} 40.00 Page 7-24 *depends on the unit
C017 œ Threshold Q
min
0.00 0.00 {0.02 Hz} 480.00 Page 7-65
C018 ¤ Chopper frequency -1- -0- 4 kHz power-loss optimised
-1- 8 kHz, power-loss optimised
-2- 12 kHz power-loss optimised
-3- 16 kHz power-loss optimised
-4- 4 kHz noise optimised
Page 7-29
-3- 16 kHz power-loss optimised
-4- 4 kHz noise optimised
-5- 8 kHz noise optimised
-6- 12 kHz noise optimised
-7- 16 kHz noise optimised
C019 œ Threshold auto DC
brake
0.10 0.00 {0.02 Hz} 5.00 Page 7-56
