Commissioning
8200SHB0199
5-2
5.2 Short commissioning (factory setting)
5.2.1 Switch-on sequence
Step
1.Connect to the mains. The controller is ready for operation after approx. 2 seconds.
2.Enter the direction of rotation. - CW rotation:
- Apply a LOW signal to terminal E4 (0 ... + 3 V).
- CCW rotation:
- Apply a HIGH signal to terminal E4 (+ 12 ... + 30 V).
3.Enter the setpoint. Apply a voltage 0 ... + 10 V to terminal 8.
4.Enable controller. Apply a HIGH signal (+ 12 ... + 30 V) to terminal 28.
5.The drive is now running with factory setting.
5.2.2 Factory setting of the most important drive parameters
Setting Code Factory setting Adaptation to the
application
Operating mode C001 -0- Setpoint selection via terminal 8
Control via terminals
Parameter setting via 8201BB See code table, chapter 7.8
for “Standard”
See code table, chapter 7.9
for “HVAC”
Terminal configuration C007 -0- E4 E3 E2 E1
CW/CCW DC injection brake JOG1/2/3
See code table, chapter 7.8
for “Standard”
See code table, chapter 7.9
for “HVAC”
Machine data Chapter 5.3 ff.
Speed range Min. field frequency C010 0.00 Hz Chapter 5.3.1 Speed range
Max. field frequency C011 50.00 Hz
Chapter 5.3.1
Acceleration
and
deceleration Acceleration time C012 5.00 s Chapter 5.3.2
and
deceleration
times
Deceleration time C013 5.00 s
Current limit
values Motor mode C022 150 % Chapter 5.3.3 Current limit
values
Generator mode C023 80 %
Chapter 5.3.3
Drive performance Chapter 5.4 ff.
Current /
torque/power/ Operating mode C014 Motor-current control, see
chapter 5.4.2.1 Current /
torque/power/
performance
820X -0- Linear characteristic V f
d
with auto
boost
Motor-current control, see
chapter 5.4.2.1
V/f-characteristic control
with auto boost, chapter
performance
821X/822X/
824X
-4- Motor-current control
- with auto boost, chapter
5.4.2.2
with V
min
boost, chapter
V/f-rated frequency C015 50.0 Hz
- with V
min
boost, chapter
5.4.2.3
V
min
-setting C016
5.4.2.3
820X
C016
type-
dependent
821X/822X/
824X
0 %
Slip compensation C021 0 %
