System Configuration Setup
System Setup Utility (SSU)
81
Removing an ISA expansion card (without CFG file)
1 Switch on the server and start the SSU.
2 Select Resources in the Tasks section.
3 Select ISA Card.
4 Select Remove ISA Card to remove the ISA resources from the system
resources.
5 Select SAVE to save the system configuration. Switch off the server.
6 Remove the server panel covers and remove the expansion card from the
ISA slot.
7 Replace the server panel covers and switch on the server and check for error
messages.
Installing an ISA expansion card (with CFG file)
1 Copy the CFG file to the SSU floppy disk 1.
2 Switch on the server and start the SSU.
3 Select Add ISA Card in the resource section.
4 Open Baseboard:System Board.
5 Select Resource use and verify or change the registration.
6 Select Save to save the system configuration.
7 Switch off the server and remove the server panel covers.
8 Change the expansion card switch and jumper settings if there was a
conflict.
9 Insert the expansion card into the ISA slot specified in Step 3.
10 Replace the server panel covers.
11 Switch on the server and check for error messages.
Removing an ISA expansion card (with CFG File)
1 Switch on the server and start the SSU.
2 Select Remove ISA Card in the Resource section and delete the expansion
card to be removed.
3 Select SAVE to save the system configuration.
4 Switch off the server and remove the panel covers.
5 Remove the expansion card from the ISA slot.
6 Replace the panels and switch on the server and check for error messages.
