148
11 PRSNT2_L O Reserved
12 GND GND
13 GND GND
14 Reserved Reserved
15 GND RST_L I
16 PCICLK I +5V(I/O)
17 GND GNT_L I/O
18 REQ_L I/O GND
19 +5V(I/O) Reserved
20 AD31 I/O AD30 I/O
21 AD29 I/O 3.3V*
22 GND AD28 I/O
23 AD27 I/O AD26 I/O
24 AD25 I/O GND
25 3.3V* AD24 I/O
26 C/BE3_L I/O IDSEL I
27 AD23 I/O 3.3V*
28 GND AD22 I/O
29 AD21 I/O AD20 I/O
30 AD19 I/O GND
31 3.3V* AD18 I/O
32 AD17 I/O AD16 I/O
33 C/BE2_L I/O 3.3V*
Pin No.
5V system environment
Side B I/O Side A I/O
