Toshiba Magnia 7010 User Manual
Page 78
Installing Hardware
Installing a second HDD cage
62
Removing the front frame and dust cover
5 Slide the HDD cage into the server and secure the cage with 8 screws.
Installing the HDD cage
6 Remove the fan module(s). For more information, see “Fan module
installation/removal” on page 37.
7 Remove two screws securing the fan unit’s rail base and lift out the rail base.
Dust cover
