Toshiba Magnia 7010 User Manual
Page 166
150
*The system board does not provide a PCI 3.3V power connector. Only the 5V PCI signaling
environment is supported, and no power is available at the 3.3V signal pins in expansion
slots.
57
GND
AD02
I/O
58
AD01
I/O
AD00
I/O
59
+5V(I/O)
+5V(I/O)
60
ACK64_L
I/O
REQ64_L
I/O
61
+5V
+5V
62
+5V
+5V
Pin No.
5V system environment
Side B
I/O
Side A
I/O
