System Configuration Setup
System Setup Utility (SSU) 80
8 Replace the server covers.
9 Restart the server and check for error messages.
The PCI expansion card’s resources are automatically set up, so it is not
necessary to restart the SSU. However, execute Resources, whenever
necessary, to verify or change the resource.
If an ISA expansion card (without CFG file) is installed, there may be a conflict
between the PCI and ISA resources, possibly preventing normal system
operation.
If necessary, remove the ISA expansion card, then change the resource
according the procedures for ISA expansion card (without CFG file)
installation and removal.
Removing a PCI expansion card
1 Remove the server panels. See“Removing and replacing the server panels”
on page 19 for details.
2 Switch off the server and remove the expansion card from the PCI slot.
3 Replace the server panels.
4 Switch on the server and check that no error message appears.
Installing an ISA expansion card (without CFG file)
1 Switch on the server and start the SSU.
2 Select Resources in the Tasks section.
3 Open Baseboard:System Board.
4 Call Resource Use on the screen and verify the available resources. Change
the resources if necessary.
5 Secure the resources for the expansion card using Define ISA, and select
Add ISA Card to add the ISA resource to the system resources.
6 Select SAVE to save the system configuration.
7 Switch off the server, remove the panel covers, and change the expansion
card switch and jumper settings to suit the resource set by Define ISA.
8 Insert the expansion card into the ISA slot.
9 Replace the cover panels.
10 Switch on the server and check for error messages.
