Interfaces
This appendix gives the connector pin-out information for the various device
interfaces.
RGB interface
NOTE: I/O indicates an input or output as viewed from the server.
.
Pin No.
Signal
Meaning
I/O
1
CRV
Red video signal
O
2
CGV
Green video signal
O
3
CBV
Blue video signal
O
4
Unused
Unused
5
GND
Signal ground
6
GND
Signal ground
7
GND
Signal ground
8
GND
Signal ground
9
Unused
Unused
10
GND
Signal ground
