C. Object directory DS402 and CI
C−18
Festo GDCP−SFC−LACI−CO−EN en 0812NH
Name } FHPP CI DS Object
PNU 402 Sub Index
Drive data 6510h 1...7 x x 1026 B.3.9
Limit switch polarity 11h x x 1300 B.3.10
Limit switch selector 12h x x 1301
Homing switch selector 13h x x 1302
Homing switch polarity 14h x x 1303
Limit switch deceleration 15h x x 1304
Sample input 16h x x 1305
Brake delay time switch on 17h x x 1310
Brake delay time switch off 18h x x 1311
Automatic brake time 19h x x 1312
Limit switch polarity 1Ch x x 1306
Output stage temperature 31h x x 1066
Max. output stage temp 32h x x 1067
Output stage lower threshold temp 33h x x 1068
Output stage upper threshold temp 34h x x 1069
Drive data 41,43,
A0h x x ć C.3
Power supply 50h x x 1070 B.3.10
Tool load 51h x x 1071
CMXR: Configuration control word F0h x x 151 B.3.4
Tab. C/1: CANopen and CI object directory
